Agras T50
$0.00
Marketing Information
DJI AGRAS T50 elevates drone agricultural operations to new heights. It inherits a powerful coaxial twin-rotor propulsion system and a split-type torque resistant structure for next level stability when carrying 40 kg spraying[1] or 50 kg spreading[1] payloads.
DJI AGRAS T50 leverages a Dual Atomizing Spraying System, Front and Rear Phased Array Radars, and a Binocular Vision System. DJI AGRAS T50 excels across multiple scenarios, from surveying[2] to spraying and spreading, guaranteeing stable operations and steady performance.
*The appearance of the product is subject to the actual product.
Heavy Payload
40 kg spraying[1]
50 kg spreading[1]
High Flow Rate
Spraying 16 L/min[3]
Spreading 108 kg/min[4]
Signal Stability
Offline operations
2 km O3 Transmission
Optional DJI Relay
All Scenario Adaptability
Fully automatic and manual operation
Orchard Mode
Variable Rate Application
Four Sprinkler Kit (Optional)
Reverse Directional Spray During Flight
4-sprinkler spraying, flow rate 24 L/min[3]
Note
[1] Data was measured at sea level. The payload weight is greatly affected by the ambient temperature and altitude. The take-off payload weight needs to be reduced by 10 kg for every 1,000 m increase in altitude. The DJI Agras app will recommend the payload weight according to the current status and surroundings of the aircraft. When adding materials, the maximum weight should not exceed the recommended value, otherwise flight safety may be compromised.
[2] RTK is required.
[3] Maximum spraying flow rate with two sprinklers is 16 L/min. Maximum spraying flow rate with four sprinklers is 24 L/min.
[4] Data measured with 4 mm diameter urea. The maximum flow rate may vary depending on the granule size, density, and surface smoothness of different fertilizers.
DJI AGRAS T50 leverages a Dual Atomizing Spraying System, Front and Rear Phased Array Radars, and a Binocular Vision System. DJI AGRAS T50 excels across multiple scenarios, from surveying[2] to spraying and spreading, guaranteeing stable operations and steady performance.
*The appearance of the product is subject to the actual product.
Heavy Payload
40 kg spraying[1]
50 kg spreading[1]
High Flow Rate
Spraying 16 L/min[3]
Spreading 108 kg/min[4]
Signal Stability
Offline operations
2 km O3 Transmission
Optional DJI Relay
All Scenario Adaptability
Fully automatic and manual operation
Orchard Mode
Variable Rate Application
Four Sprinkler Kit (Optional)
Reverse Directional Spray During Flight
4-sprinkler spraying, flow rate 24 L/min[3]
Note
[1] Data was measured at sea level. The payload weight is greatly affected by the ambient temperature and altitude. The take-off payload weight needs to be reduced by 10 kg for every 1,000 m increase in altitude. The DJI Agras app will recommend the payload weight according to the current status and surroundings of the aircraft. When adding materials, the maximum weight should not exceed the recommended value, otherwise flight safety may be compromised.
[2] RTK is required.
[3] Maximum spraying flow rate with two sprinklers is 16 L/min. Maximum spraying flow rate with four sprinklers is 24 L/min.
[4] Data measured with 4 mm diameter urea. The maximum flow rate may vary depending on the granule size, density, and surface smoothness of different fertilizers.
Detail Specifications
| Aircraft Max Takeoff WeightDefinition1 Max takeoff weight for spraying: 92 kg (at sea level) Max takeoff weight for spreading: 103 kg (at sea level) Max Diagonal Wheelbase 2200 mm Hovering Accuracy Range (with strong GNSS signal) RTK enabled: Horizontal: +/-10 cm, Vertical: +/-10 cm RTK disabled: Horizontal: +/-60 cm, Vertical: +/-30 cm (radar module enabled: +/-10 cm) RTK/GNSSOperating Frequency RTK: GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galileo E1/E5b, QZSS L1/L2 GNSS: GPS L1, GLONASS F1, BeiDou B1I, Galileo E1, QZSS L1 Max Configurable Flight Radius 2000 m Max Wind Resistance 6 m/s |
| Propulsion System - Motors Stator Size 100x33 mm KV 48 rpm/V Power 4000 W/rotor |
| Propulsion System - Propellers Material Nylon carbon fiber filament Propeller Rotation Diameter 1375 mm Quantity 8 |
| Dual Atomizing Spraying System - Spray Tank Material Plastic (HDPE) Volume 40 L Operating Payload Definition1 40 kgDefinition1 Quantity 1 |
| Dual Atomizing Spraying System - Sprinklers Model LX8060SZ Quantity 2 Nozzle Distance 1570 mmRear Nozzles Droplet Size 50-500 Micrometre Effective Spray Width Definition2 4-11 m (at a height of 3 m above the crops) |
| Dual Atomizing Spraying System - Delivery Pumps Type Impreller pump (magnetic drive) Quantity 2 Single Pump Flow Rate 0-12 L/min Max Flow Rate 16 L/min (2 sprinklers), 24 L/min (4 sprinklers) |
| T50 Spreading System Compatible Material Diameter 0.5-5 mm dry granules Spread Tank Volume 75 L Spread Tank Internal Load Definition10 50 kg Spread Width 8 m |
| Phased Array Radar System Model RD241608RF (forward phased array radar), RD241608RB (rear phased array radar) Terrain Follow Max slope in mapping-free operation: 50o Altitude detection range: 1-50 m Stabilization working range: 1.5-30 m Obstacle Avoidance Definition4 Obstacle sensing range (multidirectional): 1-50 m FOV: Forward phased array radar: horizontal 360o, vertical +/-45o, upward +/-45o (cone) Rear phased array radar: vertical 360o, horizontal +/-45o Working conditions: flying higher than 1.5 m over the obstacle at a horizontal speed no more than 10 m/s and vertical speed no more than 3 m/s. Safety limit distance: 2.5 m (distance between the front of propellers and the obstacle after braking) Sensing direction: 360o multidirectional sensing |
| Binocular Vision System Measurement range 0.5-29 m Effective Sensing Speed is less than or equal to 10 m/s FOV Horizontal: 90o, Vertical: 106o Operating Environment Adequate light and discernible surroundings |
| Remote Controller Model RM700B Operating Frequency Definition5 2.4000-2.4835 GHz, 5.725-5.850 GHz Max Transmission Distance 7 km (FCC), 5 km (SRRC), 4 km (MIC/CE), (unobstructed, free of interference, and at an altitude of 2.5 m) Wi-Fi Protocol Wi-Fi 6 Wi-Fi Operating Frequency Definition5 2.4000-2.4835 GHz, 5.150-5.250 GHz, 5.725-5.850 GHz Bluetooth Protocol Bluetooth 5.1 Bluetooth Operating Frequency 2.4000-2.4835 GHz GNSS GPS+Galileo+BeiDou Screen 7.02-in LCD touchscreen, with a resolution of 1920x1200 pixels, and high brightness of 1200 cd/m2 Operating Temperature -20o to 50o C (-4o to 122o F) Storage Temperature Range Less than one month: -30o to 45o C (-22o to 113o F) One to three months: -30o to 35o C (-22o to 95o F) Six months to one year: -30o to 30o C (-22o to 86o F) Charging Temperature 5o to 40o C (41o to 104o F) Internal Battery Runtime 3 hours 18 minutes External Battery Runtime 2 hours 42 minutes Charging Type It is recommended to use a locally certified USB-C charger at a maximum rated power of 65 W and maximum voltage of 20 V such as the DJI 65W Portable Charger. Charging Time 2 hours for internal battery or internal and external battery (when remote controller is powered off and using a standard DJI charger) |
| DB1560 Intelligent Flight Battery Model DB1560 Intelligent Flight Battery (BAX702-30000mAh-52.22V) Capacity 30000 mAh Nominal Voltage 52.22 V |
| D12000iE Multifunctional Inverter Generator Output Channel 1.DC charging output 42-59.92V/9000W 2.Power supply for Air-Cooled Heat Sink 12 V/6 A 3.AC output 230V/1500W or 120V/750W Definition8 Battery Charging TimeDefinition11 To fully charge one battery (DB1560 battery) takes 9-12 mins Fuel Tank Capacity 30 L Starting Method Starting the Generator via the One-Button Start Switch Max Power of Engine 12000 W Fuel Type Unleaded gasoline with RON is more than or equal to 91 (AKI is more than or equal to 87) and alcohol content less than 10% (Brazil: unleaded gasoline with RON is more than or equal to 91 and alcohol content of 27%) Reference Fuel Consumption Definition9 500 ml/kWh Engine Oil Model SJ 10W-40 |
| C10000 Intelligent Power Supply Model Number CSX702-9500 Input/Output Input (Main): 220-240 VAC, 50/60 Hz, 24 A MAX Input (Auxiliary): 220-240 VAC, 50/60 Hz, 24 A MAX Output: 59.92 VDC MAX, 175 A MAX, 9000 W MAX Input (Main): 100-120 VAC, 50/60 Hz, 16 A MAX Input (Auxiliary): 100-120 VAC, 50/60 Hz, 16 A MAX Output: 59.92 VDC MAX, 60 A MAX, 3000 W MAX Charging TimeDefinition11 Fully charges a battery in 9 to 12 minutes (DB1560 Intelligent Flight Battery) Protection Functions Over-voltage, over-charge, under-voltage and over-temperature protection. Charging Safety AC wire protection, power wire protection, and charge connector protection |
| Relay Model RL01-65 Input Voltage Definition6 9 V3 A / 12 V2.5 A / 15 V2 A Power Consumption 9 W (SRRC), 12 W (FCC) Capacity 6500 mAh Operating Time 4 hours Operating Frequency Definition5 2.4000-2.4835 GHz, 5.725-5.850 GHz Max Transmission Distance 5 km (SRRC), 4 km (MIC/KCC/CE), 7 km (FCC) (unobstructed, free of interference, and at a flight altitude of 2.5 m) Charging Time 2 hours and 20 minutes (when using a standard DJI charger) IP Rating Definition6 IP55 |
| Definition 1. Data was measured at sea level. The payload weight is greatly affected by the ambient temperature and altitude. The payload weight needs to be reduced by 10 kg for every 1,000m increase in altitude. The DJI Agras app will recommend the payload weight according to the current status and surroundings of the aircraft. When adding materials, the maximum weight should not exceed the recommended value, otherwise flight safety may be compromised. 2. The spray width of the spraying system depends on the operating scenario and demand for coverage evenness. 3. The spread width of the spreading system depends on the operating scenario and demand for coverage evenness. 4. The effective sensing range and its ability to avoid and bypass obstacles will vary depending on the ambient light, rain, fog, and the material, position, shape, and other properties of the obstacles. Downward sensing mainly assists in Terrain Follow and Altitude Hold. The sensing in other directions is used for Obstacle Avoidance. 5. 5.8 GHz frequency is unavailable in some contries. Check local regulations for more information. 6. Use chargers or external power supplies that meet the specifications. Otherwise, the device may not work normally. 7. The protection rating may be reduced due to improper use and damage caused by external forces or environmental factors. 8. The actual power and voltage may vary according to local regulations. 9. Measured using RON 92 gasoline at near sea level with an ambient temperature of 25o C, while charging at 9 kW. 10. The DJI Agras app will intelligently recommend the payload weight limit for the spread tank according to the current status and surroundings of the aircraft. DO NOT exceed the recommended payload weight limit when adding material to the spread tank. Otherwise, the flight safety may be affected. 11. Factors impacting charging time: Altitude of the charging station, Charging cable meets |
| Item Dimension (L inchxW inchxH inch) 48 x 43 x 34 Weight 505.00 lb Warranty Information 12 months |
